Technical Parameter

• Power adapter input: 220-240V~ 50Hz/60Hz 400mA

• Power adapter output: 25V~ 50Hz/60Hz 2.8A

• Main unit input: 25V~ 50Hz/60Hz 2.8A

• Output main vibration offset of tip (maximum): 90μm; Deviation: +50%

• Output vibrating frequency of tip: 30±5kHz

• Output semi- (maximum)offset force: 5N Deviation: +50%

• Output power of tip: 3W~20W

• Main unit fuse: T5AH 250V

• Power adapter fuse: T1.0AL250V

• Water inlet pressure: 1bar~5bar (0.1MPa~0.5MPa)

• Air inlet pressure: 5.5bar~7.5bar (0.55MPa~0.75MPa)

• Water outlet temperature of air polishing system: 0~45℃

• Main unit weight: 2.75Kg

• Main unit size: 330mm×280mm×120mm
